Advanced Drain® is an effective and eco-friendly drainage composite tough enough to handle any roof top soil load. Its durable drainage core flexes under foot and lightweight traffic, leaving an open structure for maximum, multi-directional water flow. The heavy-duty polyester filter fabric lets water pass through, but keeps soil particles from clogging the core. Advanced Drain® promotes unobstructed water and air flow to help keep the structural elements of the roof in peak condition. Advanced Drain® is available in .40 (10mm) or .50 (13mm) thicknesses.
Click below to view the virtual brochure!
Additional Information
This video explains the proper installation techniques for our Green Roof Products ; Advanced Drain (Formerly known as Watairvent Green Roof), Ground Guard RR and Ground Guard VM.
Install green roof drainage mats in accordance with manufacturer’s instructions at locations indicated on the Drawings.
Install green roof drainage mats to allow unobstructed water and air flow.
Butt green roof drainage mats together without overlapping.
Protect installed green roof drainage mats from damage during construction.
| Green Roof Drainage Mat | Core Material | Fabric Material | Thickness | Roll Size | Roll Wight | Coverage Area | UV Exposure |
| Advanced Drain® 601 | Polypropylene (Waffle) | Polyester | .40” (10 mm) | 39” X 100’ | 34 lbs. (15.42 kg) | 36.11 yd.2 (30.193 m2) | 30 Days |
| Advanced Drain® 602 | Polypropylene (Waffle) | Polyester | .50” (13 mm) | 39” X 100’ | 52 lbs. (23.57 kg) | 36.11 yd.2 (30.193 m2) | 30 Days |
